UNION
Catalogue|
METRIC |
||||||
|
Product ID |
D1 |
D2 |
H |
L1 |
L2 |
L3 |
|
mm |
mm |
mm |
mm |
mm |
mm |
|
|
U_2 mm |
2 |
1.7 |
12 |
22.4 |
35.6 |
12.9 |
|
U_3 |
3 |
2.4 |
12 |
22.1 |
35.3 |
12.9 |
|
U_4 |
4 |
2.4 |
12 |
24.1 |
37.3 |
13.7 |
|
U_6 |
6 |
4.8 |
14 |
26.2 |
41.0 |
15.3 |
|
U_8 |
8 |
6.4 |
15 |
28.2 |
43.2 |
16.2 |
|
U_10 |
10 |
7.9 |
18 |
31.0 |
46.2 |
17.2 |
|
U_12 |
12 |
9.5 |
22 |
31.0 |
51.2 |
22.8 |
|
U_14 |
14 |
11.1 |
24 |
31.8 |
52.0 |
24.4 |
|
U_15 |
15 |
11.9 |
24 |
31.8 |
52.0 |
24.4 |
|
U_16 |
16 |
12.7 |
24 |
31.8 |
52.0 |
24.4 |
|
U_18 |
18 |
15.1 |
27 |
33.3 |
53.5 |
24.4 |
|
U_20 |
20 |
15.9 |
30 |
34.8 |
55.0 |
26.0 |
|
U_22 |
22 |
18.3 |
30 |
34.8 |
55.0 |
26.0 |
|
U_25 |
25 |
21.8 |
35 |
40.4 |
65.0 |
31.3 |
|
U_28 |
28 |
21.8 |
* |
* |
85.0 |
36.6 |
|
U_B28 |
B28 |
24.6 |
* |
* |
65.4 |
31.6 |
|
U_30 |
30 |
26.2 |
* |
* |
92.7 |
39.6 |
|
U_32 |
32 |
28.6 |
* |
* |
97.3 |
42.0 |
|
U_38 |
38 |
33.7 |
55 |
58.4 |
114.0 |
49.4 |
|
U_50 |
50 |
45.2 |
3 inch |
71.7 |
146.0 |
65.0 |
|
IMPERIAL |
||||||
|
Product ID |
D1 |
D2 |
H |
L1 |
L2 |
L3 |
|
inch |
inch |
inch |
inch |
inch |
inch |
|
|
U_1/16 |
1/16 |
.05 |
5/16 |
.69 |
.99 |
.34 |
|
U_1/8 |
1/8 |
.09 |
7/16 |
.88 |
1.40 |
.50 |
|
U_3/16 |
3/16 |
.12 |
7/16 |
.95 |
1.47 |
.54 |
|
U_1/4 |
1/4 |
.19 |
1/2 |
1.03 |
1.61 |
.60 |
|
U_5/16 |
5/16 |
.25 |
9/16 |
1.11 |
1.69 |
.64 |
|
U_3/8 |
3/8 |
.28 |
5/8 |
1.19 |
1.77 |
.66 |
|
U_1/2 |
1/2 |
.41 |
13/16 |
1.22 |
2.02 |
.90 |
|
U_1/2-003 |
1/2 |
.50 |
* |
* |
4.30 |
* |
|
U_5/8 |
5/8 |
.50 |
15/16 |
1.25 |
2.05 |
.96 |
|
U_3/4 |
3/4 |
.62 |
1 1/16 |
1.31 |
2.11 |
.96 |
|
U_7/8 |
7/8 |
.72 |
1 3/16 |
1.37 |
2.17 |
1.02 |
|
U_1 |
1 |
.88 |
1 3/8 |
1.59 |
2.55 |
1.23 |
|
U_1 1/8 |
1 1/8 |
.97 |
|
|
2.55 |
1.23 |
|
U_1 1/4 |
1 1/4 |
1.09 |
1 3/4 |
1.89 |
3.63 |
1.62 |
|
U_1 1/2 |
1 1/2 |
1.34 |
2 1/8 |
2.11 |
4.25 |
1.97 |
|
U_2” |
2 |
1.81 |
2 3/4 |
2.94 |
5.88 |
2.66 |
