METRIC TO IMPERIAL

Product ID

D1

D2

D3

H

L1

L2

L3

L4

mm

inch

mm

mm

mm

mm

mm

mm

MPWC_3 x 1/8

3

1/8

2.4

12

23.9

9.7

30.5

12.9

MPWC_4 x 1/8

4

1/8

2.4

12

24.6

9.7

31.2

13.7

MPWC_6 x 1/8

6

1/8

4.8

14

25.4

9.7

32.8

15.3

MPWC_6 x 1/4

6

1/4

4.8

14

30.5

14.2

37.9

15.3

MPWC_8 x 1/8

8

1/8

5.1

15

26.7

9.7

34.2

16.2

MPWC_8 x 1/4

8

1/4

6.4

15

31.2

14.2

38.7

16.2

MPWC_8 x 1/2

8

1/2

6.4

22

38.1

19.0

45.6

16.2

MPWC_10 x 1/4

10

1/4

7.1

18

33.3

14.2

40.9

17.2

MPWC_10 x 3/8

10

3/8

7.9

18

33.3

14.2

40.9

17.2

MPWC_10 x 1/2

10

1/2

7.9

22

38.9

19.0

46.5

17.2

MPWC_12 x 1/4

12

1/4

7.1

22

33.3

14.2

43.4

22.8

MPWC_12 x 3/8

12

3/8

9.5

22

33.3

14.2

43.4

22.8

MPWC_12 x 1/2

12

1/2

9.5

22

38.9

19.0

49.0

22.8

MPWC_12 x 3/4

12

3/4

9.5

27

40.4

19.0

50.5

22.8

MPWC_14 x 3/8

14

3/8

10.4

24

34.0

14.2

44.1

24.4

MPWC_15 x 1/2

15

1/2

11.9

24

38.9

19.0

49.0

24.4

MPWC_16 x 1/2

16

1/2

12.7

24

38.9

19.0

49.0

24.4

MPWC_18 x 1/2

18

1/2

13.5

27

40.4

19.0

50.5

24.4

MPWC_30 x 1 1/4

30

1 1/4

MPWC_32 x 1 1/4

32

1 1/4

MPWC_38 x 1 1/2

38

1 1/2

33.7

55

64.0

26.2

91.2

49.4

IMPERIAL TO IMPERIAL

Product ID

D1

D2
(Straight Thread UN)

D3

H

L1

L2

L3

L4

O-Ring

inch

inch

inch

inch

inch

inch

inch

inch

MPWC_1/8 x 1/8

1/8

1/8

10.30

2.28

7/16

23.88

9.65

30.48

12.7

MPWC_3/16 x 1/8

3/16

1/8

10.30

3.04

7/16

24.60

9.65

31.25

13.7

MPWC_1/4 x 1/8

1/4

1/8

10.30

4.82

1/2

25.40

9.65

32.77

15.2

MPWC_1/4 x 1/4

1/4

1/4

13.70

4.82

9/16

30.48

14.22

37.85

15.2

MPWC_5/16 x 1/8

5/16

1/8

10.30

5.08

9/16

26.67

9.65

34.04

16.2

MPWC_5/16 x 1/4

5/16

1/4

13.70

6.35

9/16

31.24

14.22

38.61

16.2

MPWC_3/8 x 1/4

3/8

1/4

13.70

7.11

5/8

32.51

14.22

39.87

16.8

MPWC_3/8 x 3/8

3/8

3/8

17.10

7.11

11/16

32.51

14.22

39.87

16.8

MPWC_3/8 x 1/2

3/8

1/2

21.34

7.11

7/8

38.86

19.05

46.22

16.8

MPWC_3/8 x 3/4

3/8

3/4

26.67

7.11

1 1/16

40.38

19.05

47.75

16.8

MPWC_1/2 x 3/8

1/2

3/8

17.10

10.41

13/16

33.27

14.22

44.43

22.9

MPWC_1/2 x 1/2

1/2

1/2

21.34

10.41

7/8

38.86

19.05

49.00

22.9

MPWC_1/2 x 3/4

1/2

3/4

26.67

10.41

1 1/16

40.40

19.05

50.55

22.9

MPWC_1/2 x 1

1/2

1

33.40

10.41

1 3/8

47.50

23.87

57.65

22.9

MPWC_5/8 x 1/2

5/8

1/2

21.34

12.70

15/16

38.86

19.05

49.02

24.4

MPWC_3/4 x 1/2

3/4

1/2

21.34

13.46

1 1/16

38.86

19.05

49.00

24.4

MPWC_3/4 x 3/4

3/4

3/4

26.67

15.74

1 1/16

40.40

19.05

50.55

24.4

MPWC_1 x 1

1

1

33.40

22.35

1 3/8

50.03

23.87

62.23

31.2

MPWC_1 1/4 x 1 1/4

1 1/4

1 1/4

42.16

27.70

1 3/4

55.12

23.88

77.22

41.2

MPWC_1 1/2 x 1 1/2

1 1/2

1 1/2

48.26

34.00

2 1/8

61.72

26.16

88.90

50.0

MPWC_2 x 2

2

2

60.33

45.97

2 3/4

76.20

26.92

113.34

67.6
